C680-B1 (7M/9M) Solar CCTV Trailer
A two-panel solar CCTV configuration with a choice of 7 m or 9 m mast.
PRODUCT OVERVIEW
Build the discussion around the site.
C680-B1 (7M/9M) Solar CCTV Trailer is listed in the supplied STG 2026 product catalogue. Use the reference configuration below to begin a site-specific discussion; final equipment selection, performance and availability require confirmation with STG.
Planning considerations
- Plan fixed and PTZ camera positions around the required field of view.
- Confirm the network, recording and remote-access requirements.
- Size the final energy configuration around the camera load and local solar resource.
Application planning
- Temporary compound surveillance
- Remote asset visibility
- Relocatable camera coverage
Reference specifications
- Solar array
- 2 × 480 W (960 W)
- Battery energy
- 10,240 Wh (LFP)
- Reference cameras
- 1 PTZ + 3 bullet cameras
- Camera resolution
- 5 megapixels
- Mast options
- 7 m / 9 m
Reference values from the supplied 2026 catalogue, not a project guarantee. Confirm final configuration, performance and availability with STG.
Source: STG Product Catalogue 2026, page 36 (opens in a new tab).
Technical reference & downloads
The original catalogue table is included for reference. Ask STG to clarify any incomplete or inconsistent source values.
View the original technical table
Open the technical table image in a new tabBROWSE BY CATEGORY
